Y83-250 Scrap Metal Baler

Our Y83-250 scrap metal baler is the product with bale turning system. It is primarily applied in the metal smelting factory with mediem and large output, scrap metal materials processing and recycling station. This product is widely favored by cutomers in Russia and Ukraine, who wll purchase this type of product every month.

The remarkable advantages of this scrap metal baler are represented by manual operation, low failure rate and high efficiency. Its houly output reaches 5 to 8tons. The compacting box can be fabricated in the specification of 2000mm×1400mm×900mm and 2000mm×1750mm×1200mm. The size of the compressed bale is 500mm×500mm. Users have the option of power system of 60kw or 74kw as they need. More information can be obtained from our specialized sales deparment.

Technical Parameters
No. Parameters Note
1 Main Hydraulic Cylinder Model YG340/220-950 Quantity 1pcs
Nominal Thrust 2500kN Stroke 950mm
2 Side Hydraulic Cylinder Model YG220/160-1560 Quantity 2pcs Double cylinders in parallel
Nominal Thrust 1000 kN×2 Stroke 1560mm
3 Lid Cylinder Model YG200/140-1350 Quantity 1pcs
Nominal Thrust 800kN Stroke 1350mm
4 Turn-out Cylinder Model YG125/80-395 Quantity 1pcs
Nominal Thrust 80kN Stroke 395 mm
5 Hydraulic System Pressure 25 MPa (Max. Pressure 27MPa)
6 Oil Tank Capacity 2160L
7 Compacting Box Size 2000mm×1400mm×900mm
8 Thickness of Baled Material Common metal mateials
9 Bale Size (450~800)mm×500mm×500mm
10 Bale Density ≥ 1800kg/m3
11 Control Mode Manual control
12 Single Cycle Time About 120s
13 Oil Pump Model 160YCY14-1B Rated Pressure 31.5MPa
Flow Quantity 160ml/r Quanity 2pcs
14 Motor Model Y225M-6 Rated Rotating Speed 980rpm
Power 30kw Quanity 2pcs
15 Overall Dimension 2000mm× 1400mm×900mm
16 Machine Weight 19.5ton
